| DC 110v to AC 220v Converter Specification | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Power | 1000VA | 2000VA | 3000VA | 4000VA | 5000VA | 6000VA | 8KVA | 10KVA | 12KVA |
| DC Input | |||||||||
| Rated input voltage | 110Vdc | ||||||||
| Backflow noise current | ≤10% | ||||||||
| Mains input | |||||||||
| Allow bypass voltage | 180Vac~285Vac(±1%) | ||||||||
| Rated input current | 4.5A | 9A | 13.6A | 18A | 22.6A | 27A | 36A | 45A | 54A |
| Bypass transfer time | ≤5ms | ||||||||
| AC output | |||||||||
| Rated Capacity | 1000VA | 2000VA | 3000VA | 4000VA | 5000VA | 6000VA | 8KVA | 10KVA | 12KVA |
| Rated output power | 800W | 1600W | 2400W | 3200W | 4000W | 4800W | 6400W | 8000W | 9600W |
| Rated output voltage and frequency | 220Vac,50HZ | ||||||||
| Rated output current | 3.6A | 7.2A | 10.8A | 14.4A | 18A | 21.5A | 29A | 36A | 43A |
| Output voltage accuracy | 220Vac ± 1.5% | ||||||||
| Output frequency accuracy | 50Hz ± 1% | ||||||||
| Waveform distortion rate(THD) | ≤3%(Linear load) | ||||||||
| Dynamic response time | 5%(Load 0←→100%) | ||||||||
| Power factor(PF) | 0.8 | ||||||||
| Overload capacity | 120%,30 Seconds | ||||||||
| Inverter efficiency | ≥88%(80% Resistive load) | ||||||||
| Bypass transfer time | ≤5ms | ||||||||
| Working Environment | |||||||||
| Insulation strength (input and output) | 1500Vac,1 minute | ||||||||
| Noise(1 meter) | ≤40dB | ||||||||
| Ambient temperature | -25℃~+50℃ | ||||||||
| Humidity | 0~90%,No condensation | ||||||||
| Operating altitude | ≤1000m Or Derating use | ||||||||
| Protection | Input under-voltage, input over-voltage protection; output overload, output short-circuit protection | ||||||||
