| 1. Rectifier System Input Characteristics | ||||
| No. | Items | Technical Specifications | Unit | Remarks |
|---|---|---|---|---|
| 1.1 | Input rated voltage | 200—240 | Vac | |
| 1.2 | Input voltage range | 90—264 | Vac | |
| 1.3 | Input Current | ≤27 | A | Lowest input voltage, rated load |
| 1.4 | inputvoltage frequency | 50/60 | Hz | |
| 1.5 | Power factor | ≥0.99 | - | rated input voltage, rated load |
| 1.6 | Input Shock Current | ≤30 | A | 264Vac |
| 2. Output Characteristics | ||||
| No. | Items | Technical Requirements | Unit | Remarks |
| 2.1 | Output Rated Voltage | 54 | Vdc | |
| 2.2 | Output current range | 0—100 | A | Input voltage: 176—264Vac. |
| 0—50 | A | Input voltage: 90—175Vac | ||
| 2.3 | Output voltage range | 53.5 | Vdc | |
| 2.4 | Efficiency | ≥95% | - | 220Vac input, output 54Vdc/50A. |
| ≥92% | - | 110Vac input, output 54Vdc/15A. | ||
| 2.5 | Output ripple & noise | ≤200 | mVp-p | Rated load, frequency band is limited to 20MHz |
| 2.6 | Turn-on output delay | 3—8 | S | Vin=220Vac |
