| System Integration Configuration | |||||
|---|---|---|---|---|---|
| Configuration | Rectifier | Module Qty | Distribution | Monitoring | Remark |
| Optional Configuration | 30A | 1-3 pcs | AC Distribution: AC220V input Load Output: 10A-90A |
Monitor Included | Specific index refers to module specification |
| Power System Performance Index - Input | |||||
|---|---|---|---|---|---|
| Parameter | Min. | Rated | Max. | Unit | Note |
| Rated working voltage | - | 110/220 | - | Vac | - |
| Input voltage | 90 | 220 | 280 | Vac | Three-phase five-wire input phase-to-phase 380V / relative zero line 220VAC |
| Input frequency | 43 | 50 | 67 | Hz | - |
| Battery input | 40 | 48 | 60 | Vdc | Battery pack positive and negative in parallel with DC output of rectifier module |
| Power System Performance Index - Output | |||||
|---|---|---|---|---|---|
| Parameter | Min. | Rated | Max. | Unit | Note |
| Output voltage range | 42 | 48 | 58 | Vdc | - |
| Output current range | 0 | - | 90 | A | Input 170 ~ 285VAC; output derates when input voltage falls below 170VAC |
| Regulation accuracy | - | - | ±1 | % | - |
| Load regulation | - | - | ±1 | % | - |
| Source regulation | - | - | ±1 | % | - |
| Current sharing regulation | - | - | ±5 | % | - |
| Ripple (peak-to-peak) | - | - | 200 | mv | Network 20MHz testing |
| Output efficiency | 91 | 93 | ±1 | % | 220Vac Input |
With years of export experience along with excellent quality, advanced services, and competitive prices, we have won numerous customers' trust and support globally.
Packaging Details: Export standard packing: Plastic bag + Bubble bag + Inner carton + Outer carton. Customized packaging is acceptable. We can also provide small and large PVC packing solutions based on customer needs.
Delivery Detail: 3-5 days after order confirmation.
