| Type | Name | Specification | |
|---|---|---|---|
| Input | Input mode | 3-phase 4-wire system | |
| Input voltage | 380Vac ± 20% | ||
| Frequency | 45 ~ 55Hz | ||
| Output | Output branch | Dependant on actual situation | |
| Float Charge (FC) voltage | 198 ~ 260Vdc | 99 ~ 130Vdc | |
| Boost Charge (BC) voltage | 220 ~ 286Vdc | 110 ~ 143Vdc | |
| Ripple coefficient | ≤ 0.5% (typical: 0.5%) | ||
| Voltage stabalization | ≤ ±0.5% (typical: 0.1%) | ||
| Current stabalization | ≤ ±0.5% | ||
| Inter-rectifier current imbalance | ≤ ±5% | ||
| Protection | Input over-voltage switching point | 470 ± 5Vac | |
| Input under-voltage switching point | 324 ± 4Vac | ||
| Rectifier output under-voltage alarm | 198V | ||
| Insulation | Output-ground | 2kVac, current leakage ≤30mA; time: 1min, no flashover | |
| Input-ground | |||
| Input-output | |||
| Ambient temperature | Working ambient temperature | -5°C ~ 40°C | |
| Storage ambient temperature | -25°C ~ 55°C | ||
| Acoustic noise | ≤55dB (1m in front of the cabinet) | ||
| Mechnical | Sizes (single cabinet) (H × W × D) | 2260 mm × 800mm × 600mm | |
We always guarantee quality through a pre-production sample before mass production and a final inspection before shipment.
You can purchase power supplies, power inverters, DC converters, rectifier module power systems, and battery power chargers.
We are a leading manufacturer of telecom power supplies, electric power supplies, DC-DC converters, integrated power cabinets, and parallel inverter power systems, providing high efficiency, hot-pluggable designs, and N+1 backup configurations.
The system features an efficiency of 92%. By using autonomous current-sharing technology, the maximum unbalance degree between the modules is kept below 5%.
It features comprehensive built-in protection against overcurrent, overtemperature, overloading, overpower, overvoltage, and undervoltage risks to ensure optimal system safety.
